Beamex MC6

Advanced Field Calibrator and Communicator.

Beamex MC6: The Ultimate All-in-One Process Calibrator – Now Available at YGEN Automation

Combining advanced functionality with ease of use. Execute calibrations automatically, capture data digitally at source, and store calibration results securely. The Beamex MC6 is a high-accuracy field calibrator that offers calibration capabilities for pressure, temperature, and various electrical signals. It is also a multi-bus field communicator for fieldbus instruments.

Features:

High accuracy
The MC6 is a reliable and stable calibrator with unmatched accuracy for demanding industrial conditions. Each MC6 is delivered with a traceable, accredited calibration certificate as standard as proof of its accuracy.
Advanced functionality
The MC6 is a multifunction calibrator and multi-bus communicator with calibration capabilities for pressure, temperature, and various electrical signals. It offers many features that support your calibration process and can perform fully automatic calibrations. It also offers versatile functionalities beyond traditional calibration applications.
Enhanced usability
The MC6 offers several intuitive user interface modes optimized for different use cases and available in multiple languages. The calibrator guides you step-by-step in your calibration work.
Field communicator
The MC6 contains a multi-bus field communicator for HART, FOUNDATION Fieldbus, and Profibus PA protocols to calibrate, configure, and trim your smart instruments. All three protocols can be enabled simultaneously.
Digital data flow
The MC6 is a documenting calibrator that communicates with Beamex calibration management software, enabling a fully digitalized calibration process.

Capabilities:

Measurement, generation and simulation capabilities
Pressure measurement (internal/external pressure modules)
Voltage measurement (±1 V and −1…60 VDC)
Current measurement (±100 mA) (internal or external supply)
Frequency measurement (0…50 kHz)
Pulse counting (0…10 Mpulse)
Switch state sensing (dry/wet switch)
Built-in 24 VDC loop supply (low impedance, HART impedance or FF/PA impedance)
Voltage generation (±1 V and −3…24 VDC)
Current generation (0…55 mA) (active/passive, i.e. Internal or external supply)
Resistance measurement, two simultaneous channels (0…4 kΩ)
Resistance simulation (0…4 kΩ)
RTD measurement, two simultaneous channels
RTD simulation
TC measurement, two simultaneous channels (universal connector/mini-plug)
TC simulation
Frequency generation (0…50 kHz)
Pulse queue generation (0…10 Mpulse)
HART communicator
FOUNDATION Fieldbus communicator
Profibus PA communicator

The Beamex MC6 is a high-precision, multifunctional process calibrator and communicator that redefines the standard for field and laboratory calibration. Engineered for advanced industrial environments, the MC6 combines versatility, usability, and uncompromised accuracy, making it the perfect choice for professionals in automation, instrumentation, and process industries.

As the authorized channel distributor of Beamex in Bangladesh, YGEN Automation proudly offers the MC6 along with full technical support and calibration services, ensuring maximum performance across all applications.

What is Beamex MC6?

The MC6 is an advanced portable process calibrator that integrates calibration and communication functions in a single, robust platform. It can measure and source signals for pressure, temperature, electrical, and frequency parameters, while also functioning as a HART, FOUNDATION Fieldbus, and Profibus PA communicator.

Key Features & Capabilities

Multifunctionality – Calibrates pressure, temperature, voltage, current, resistance, frequency, and more
Built-in Communicator – Supports HART, FOUNDATION Fieldbus, and Profibus PA protocols
High Accuracy – Industry-leading accuracy ensures compliance in regulated industries like pharma, food, and energy
Touchscreen Interface – Intuitive, smartphone-style GUI with multiple user interface modes
Field & Lab Use – Lightweight yet durable for on-site calibration; precise enough for lab environments
Documentation-Ready – Integrates with Beamex CMX and LOGiCAL for paperless calibration and reporting
Intrinsically Safe Model – For hazardous environments (ATEX, IECEx, and North American certifications)

Why Beamex MC6 is the Best Choice for Industrial Calibration

All-in-One Device – Eliminates the need for multiple tools
Time & Cost Efficiency – Speeds up calibration processes with built-in automation and documentation
Traceable Accuracy – Calibrated to international standards with a wide metrological range
Rugged Design – Designed for harsh field environments, backed by premium build quality
Long Battery Life – Ideal for extended on-site calibration tasks

Technical Specifications (Snapshot)

Voltage: ±1000 mV / ±30 V
Current: ±50 mA (with loop supply)
Resistance/RTD/Thermocouple Inputs: Built-in cold junction compensation
Frequency: Up to 20 kHz
Pressure Modules: Compatible with external Beamex pressure modules up to 1000 bar
Display: 5.7” color touchscreen, IP65-rated
Memory & Connectivity: USB, Ethernet, and wireless options

Industries Served

Pharmaceuticals & API plants
Food & Beverage Processing
Oil & Gas and Power Generation
Chemical Manufacturing
Water & Wastewater Treatment

YGEN Engineering Ltd. & YGEN Automation: Your Trusted Beamex MC6 Partner in Bangladesh

As the authorized channel partner of Beamex, YGEN offers:

Genuine Beamex MC6 units with warranty
Expert guidance on configuration and application
On-site training and demo support
Local after-sales service, calibration support, and integration with CMX software

SEO Keywords for Optimization

Beamex MC6 calibrator Bangladesh
Process calibrator with HART communicator
Multifunction calibrator for pharma
Field calibrator for instrumentation
Buy Beamex MC6 in Bangladesh
Best industrial calibration tool
Process calibration services YGEN Automation
Beamex authorized distributor Bangladesh

YGEN Automation – Powering Bangladesh’s automation future with world-class instrumentation and calibration tools.

Beamex MC6-Ex

Beamex MC6-Ex: Intrinsically Safe Advanced Field Calibrator & Communicator – Now from YGEN Automation

When precision meets safety, you get the Beamex MC6-Ex—the world’s most advanced intrinsically safe multifunction calibrator and communicator, designed for use in hazardous areas (Zone 0/1/2) without compromise. It offers unmatched capability, combining multi-parameter calibration, field communication, and rugged reliability, all certified for explosive environments.

As the authorized channel partner of Beamex in Bangladesh, YGEN Automation proudly supplies, supports, and services the MC6-Ex, enabling safe, accurate, and efficient calibration in industries where safety and precision are paramount.

What is Beamex MC6-Ex?

The Beamex MC6-Ex is an intrinsically safe process calibrator and communicator tailored for use in hazardous and explosive environments such as oil & gas, petrochemical, chemical, and pharmaceutical plants. It provides advanced capabilities to measure and source pressure, temperature, and electrical signals, while also functioning as a HART, FOUNDATION Fieldbus, and Profibus PA communicator—all in one certified device.

Why MC6-Ex is the Industry’s Best Choice

Zone 0 Certified – Intrinsically safe for use in the most hazardous environments
Multifunctional – Combines a calibrator and communicator in one rugged unit
High Accuracy & Stability – Calibrates pressure, temperature, and electrical parameters to exacting standards
Full Field Communication – HART, FF, and Profibus PA protocols for smart device configuration
Safe + Smart Interface – Large 5.7” touchscreen, glove-compatible, even in harsh field conditions
Documentation-Ready – Seamless integration with Beamex CMX and LOGiCAL for paperless workflow
Battery Powered for Field Use – Long-lasting rechargeable battery designed for extended on-site tasks

Key Features & Facilities

Safe for Zone 0/1/2 use – ATEX, IECEx, and North American certifications
5 Operating Modes – Calibrator, Documenting Calibrator, Data Logger, Communicator, and Meter
Compatible with External Pressure Modules – For expanded pressure ranges
Intuitive Touch Interface – Smartphone-style UI designed for industrial users
IP65-Rated – Dustproof and water-resistant for rugged environments

Core Applications in Critical Industries

Oil & Gas Refineries and Exploration
Petrochemical Plants
Chemical Manufacturing
Pharmaceuticals & Cleanroom Environments
Power Plants & Utilities with Hazardous Zones

Technical Snapshot

Voltage: ±1000 mV / ±30 V
Current: ±50 mA (including loop supply)
RTD / Thermocouple Inputs: With cold junction compensation
Frequency: Up to 20 kHz
Communication: HART, FOUNDATION Fieldbus, Profibus PA
Display: 5.7” high-brightness, glove-compatible touchscreen
Certifications: ATEX, IECEx, UL, CSA (Zone 0/Class I Div 1)

YGEN Automation – Your Trusted Source for MC6-Ex in Bangladesh

As the authorized channel distributor of Beamex, YGEN Engineering Ltd. and YGEN Automation deliver:

Genuine Beamex MC6-Ex units with global certifications
Industry-specific consultation and configuration support
On-site training and demo sessions
Local calibration support, service, and integration with Beamex CMX software

SEO Keywords for Optimization

Intrinsically safe calibrator Bangladesh
Beamex MC6-Ex dealer Bangladesh
Process calibrator for hazardous areas
HART communicator Zone 0
Advanced calibrator for oil & gas
Beamex authorized distributor Dhaka
Multifunction calibration device Ex certified
MC6-Ex documentation-ready calibrator
Calibration tools for explosive zones

YGEN Automation – Advancing safe, smart, and scalable calibration solutions for Bangladesh’s critical industries.

Beamex MC6-T

Beamex MC6-T: Precision Redefined in Temperature Calibration – Now with YGEN Automation

The Beamex MC6-T is a next-generation multifunction temperature calibrator and communicator, purpose-built for industries demanding high accuracy, versatility, and documentation-ready calibration. Combining a state-of-the-art temperature dry block with a powerful, full-featured process calibrator and communicator, the MC6-T is the ideal solution for temperature calibration in pharmaceutical, food & beverage, energy, and chemical industries.

As the authorized channel partner of Beamex, YGEN Automation proudly delivers the MC6-T along with expert support, local servicing, and industry-specific calibration solutions across Bangladesh.

What is the Beamex MC6-T?

The MC6-T is a modular and multifunctional temperature calibration system that integrates a temperature dry block, high-accuracy reference measurement, and a multifunction process calibrator—all in a single, portable unit. It offers an intuitive interface, world-class accuracy, and the ability to document and automate calibration procedures with ease.

Key Features & What It Does

Multifunction Calibrator – Calibrates RTDs, thermocouples, temperature transmitters, and other field devices
Integrated Dry Block – Wide temperature range with fast heating and cooling cycles
Reference Sensor Input – Ensures traceable and highly accurate temperature readings
Built-in Field Communicator – Supports HART, FOUNDATION Fieldbus, and Profibus PA protocols
Fully Automated & Paperless – Works seamlessly with Beamex LOGiCAL or CMX software for documented workflows
Smart UI – Large 5.7" touchscreen with customizable user modes for field, lab, or regulated environments
Portable & Rugged – Industrial-grade build for both lab and field use

Why MC6-T is the Best for Temperature Calibration

Unmatched Accuracy – Combines reference-level measurement with dry block stability
Efficiency – Calibrates multiple devices in one setup, drastically reducing downtime
Versatility – Ideal for cleanrooms, sterilization validation, CIP/SIP loops, and temperature control systems
Compliance Ready – Fully traceable and supports regulatory requirements (GMP, ISO, FDA, etc.)
User-Centric Design – Intuitive touchscreen, built-in automation, and robust safety features

Technical Highlights

Temperature Range: –30°C to +660°C (model-dependent)
Stability: Up to ±0.005 °C
Accuracy: Up to ±0.01 °C with reference probe
Electrical Measurement: mA, V, Ohms, frequency for transmitter calibration
Protocols Supported: HART, FF, Profibus PA
User Modes: Calibrator, Documenting Calibrator, Data Logger, Meter, Communicator
Software Integration: LOGiCAL cloud or Beamex CMX for full documentation and traceability

Ideal for Industries Like

Pharmaceutical & API manufacturing
Food & Beverage processing plants
Energy and Power generation
Chemical plants & process industries
Water treatment & utility services

YGEN Automation – Your Certified Beamex MC6-T Partner in Bangladesh

YGEN Engineering Ltd. and YGEN Automation are your trusted Beamex channel distributor, offering:

Genuine MC6-T calibrators with international warranty
Industry-specific consultation and application support
On-site setup, training, and integration with calibration software
After-sales service and calibration solutions tailored to your operation

SEO-Optimized Keywords

Beamex MC6-T dealer Bangladesh
Multifunction temperature calibrator
Industrial temperature calibration tool
Dry block calibrator with communicator
Pharma-grade temperature calibration
HART temperature transmitter calibrator
Beamex calibration tools in Dhaka
MC6-T process calibrator for food & beverage
Calibration documentation tool for GMP compliance

YGEN Automation – Elevating industrial precision with trusted brands and reliable calibration tools. Optimize your temperature-critical operations with the Beamex MC6-T.
